家电稳定测试

家电稳定性测试平台
Platform for stability test of household appliances

基础参数THE UNDERLYING PARAMETERS
技术规格及参数:  Technical specifications and parameters:
1、型号:600/800/1000
1. Model: 600/800/1000
2、台面直径：600MM /800MM /1000MM
2. Table diameter: 600mm / 800mm / 1000mm
3、台面材料：优质喷涂钢板
3. countertop material: high-quality spray-coated steel plate
4、角度范围：0-30°
4. Angle range: 0-30
5、承载能力：50KG/80KG/120KG
5. Load capacity: 50kg/80kg/120kg
6、旋转方式旋转速度：手动/电动-/1R/MIN
6. Rotation mode and speed: manual/electrical/1R/MIN
本装置符合GB4706-1第20.1条、IEC60335-1第20.1条等标准要求，装置由一个工作台面和角度调节装置组成,适用于需要在一个表面上工作的家电等器具进行稳定性试验。如电冰箱、洗衣机空调器等家电及类似电器或其他产品，将测试样品放置台面通过不同的角度倾斜考核其机械稳定性能。
This device complies with standards such as GB4706-1 Article 20.1 and IEC60335-1 Article 20.1. It consists of a work surface and an angle adjustment mechanism, designed for stability testing of household appliances requiring surface operation. For appliances like refrigerators, washing machines, air conditioners, and similar products, the test sample is placed on the surface and tilted at various angles to evaluate its mechanical stability.

本装置抗振性能好，承载重量大，角度可调范围广，操作简单，针对家电产品种类繁多的情况，多种规格型号的稳定试验台可选。
The device has good anti-vibration performance, large load capacity, wide adjustable range, simple operation, and can be selected from various specifications and models of stability test bench according to the variety of household appliances.
